Ultra-Precision Voltage Reference Source
The JZ-UPR (Ultra-Precision Reference) is an ultra-precision voltage reference source built upon the industry-leading LTZ1000 reference chip. It has been deeply optimized for long-term stability and ultra-low noise performance in real-world engineering environments. Featuring an ultra-low noise density of 0.2 ppm/√Hz (@0.1 Hz), it is ideally suited for high-end measurement systems, scientific research equipment, and metrology instruments sensitive to voltage stability and low-frequency noise. Internally, the JZ-UPR incorporates multi-stage thermal isolation, low-noise power filtering, precision-matched high-stability resistor networks, along with temperature compensation and long-term drift control. It can serve as a laboratory standard reference source or be embedded into systems as a high-precision voltage reference for ADCs and DACs.
Product Highlights
⭐ Ultra-Low Noise Performance: 0.2ppm/√Hz（@0.1Hz）
📈 High-Stability Output: Nominal 7.18 V output with long-term drift < 2ppm (typical)
🌡️ Low Temperature Coefficient: < 0.05ppm/°C (typical)
🔒 Multi-Stage Thermal Isolation: Effectively suppresses external thermal fluctuation interference
⚡ Low-Noise Power Conditioning: No special requirements for the external power supply system
🔌 Standard Banana Output Interfaces: Fully compatible with standard laboratory measurement equipment
🧊 Ultra-Low Power Consumption: Total power consumption < 0.8 W, optimized for continuous long-term operation
Product Highlights
⭐ Ultra-Low Noise Performance: 0.2ppm/√Hz（@0.1Hz）
📈 High-Stability Output: Nominal 7.18 V output with long-term drift < 2ppm (typical)
🌡️ Low Temperature Coefficient: < 0.05ppm/°C (typical)
🔒 Multi-Stage Thermal Isolation: Effectively suppresses external thermal fluctuation interference
⚡ Low-Noise Power Conditioning: No special requirements for the external power supply system
🔌 Standard Banana Output Interfaces: Fully compatible with standard laboratory measurement equipment
🧊 Ultra-Low Power Consumption: Total power consumption < 0.8 W, optimized for continuous long-term operation
Application Fields
01 Quantum Precision Measurement Systems
02 Laser Frequency Locking & Stabilization
03 Voltage Reference for High-Precision DAC/ADC Systems
04 High-Stability Standard Reference Sources for Laboratories
05 Scientific Research in Physics, Metrology, and Materials Science
06 Gravitational Wave Detection & Atomic Interferometry
Application Fields
01 Quantum Precision Measurement Systems
02 Laser Frequency Locking & Stabilization
03 Voltage Reference for High-Precision DAC/ADC Systems
04 High-Stability Standard Reference Sources for Laboratories
05 Scientific Research in Physics, Metrology, and Materials Science
06 Gravitational Wave Detection & Atomic Interferometry
Specifications
JZ-UPR-01
| Parameter | Specification |
| Output Voltage | 7.18 V (Customizable) |
| Initial Accuracy | ±2 ppm |
| Short-Term Stability | < 1 ppm/24 hours |
| Long-Term Drift | < 2 ppm |
| Temperature Coefficient | < 0.05 ppm/°C |
| Noise Density (@ 0.1 Hz) | <0.2 ppm/√Hz |
| Output Current Capability | ≤10 mA |
| Output Resistance | < 0.1 Ω |
| Warm-Up / Stabilization Time | ≤20 minutes |
| Interface Type | Banana Plugs or other custom standard connectors |
| Enclosure Shielding | Shielded aluminum alloy metal enclosure with grounding |
| Operating Temperature | 15°C ~ 35°C |
| Enclosure Thermal Isolation | Multi-layer thermal isolation architecture |
| Power Input | 15V DC |
| Power Consumption | < 0.8 W |
Specifications
JZ-UPR-01
| Parameter | Specification |
| Output Voltage | 7.18 V (Customizable) |
| Initial Accuracy | ±2 ppm |
| Short-Term Stability | < 1 ppm/24 hours |
| Long-Term Drift | < 2 ppm |
| Temperature Coefficient | < 0.05 ppm/°C |
| Noise Density (@ 0.1 Hz) | <0.2 ppm/√Hz |
| Output Current Capability | ≤10 mA |
| Output Resistance | < 0.1 Ω |
| Warm-Up / Stabilization Time | ≤20 minutes |
| Interface Type | Banana Plugs or other custom standard connectors |
| Enclosure Shielding | Shielded aluminum alloy metal enclosure with grounding |
| Operating Temperature | 15°C ~ 35°C |
| Enclosure Thermal Isolation | Multi-layer thermal isolation architecture |
| Power Input | 15V DC |
| Power Consumption | < 0.8 W |
